Horiba Instruments
Bench Top
New Yumizen H500 & H550
Hematology Analyzer
The new Yumizen H500 & H550 are compact benchtop hematology analyzers with enhanced performance, new features and increased benefits. Ideal for small labs and meet a variety of clinical lab environments and settings: routine hematology, satellites labs, oncology care, blood banks. Infectious flags for Malaria and Dengue are optional. The new remote assistance Yumicare is connected.
Features:
• 60 tests/hour
• Multi analysis modes: standard, prediluted, eQC,…
• Whole blood 20 µL sampling
• Only 2 reagents for Diff analysis
• 37 parameters menu with extended differential WBC count : IML, IMM, IMG, ALY
• Bidirectional connection in ASTM and HL7
• 40 tubes autonomy with continuous loading and STAT mode
• New graphical interface with color-coded menus
• QC management: iQC indicators, overlapping QC, repeatability testing mode
• Optional infectious screening flags for Malaria & Dengue
• Yumicare remote assistance service
Yumizen G200
Hemostasis Analyzer
Semi Automated Hemostasis Instrument
Compact 2-channel instrument device dedicated for small laboratories to perform hemostasis screening and DDimers tests.
Smart way to test:
• 2 independent measuring channels
• Easy to operate, innovative user interface
• QC management
• Master calibration curve (no calibration needed)
Comprehensive security:
• Bar code reading capability
• External data storage (USB device)
• Reagent ready to use
Increase efficiency:
• 3 reference measuring methods: clotting, immuno-turbidimetric and chromogenic
• 120 sec maximum measurement
• Maintenance free
User friendly features:
• 1’000 data storage capacity
• External printer connectivity
• Multiple connectivities
Yumizen CA60
Semi-automated Clinical Chemistry Analyzer
Yumizen CA60 is a compact semi-automatic clinical chemistry analyzer based on the Vertical Overlay Concept Design (VOCD), equipped with durable Multi Array Light System (MALS).
Wide Test Menu:
• Pre-programmed biochemistry & turbidimetric tests: Ready to use Yumizen CR Clinical Chemistry Reagents
• Multiple user programs can be stored
• Separate QC file: Easy quality monitoring
User Friendly Interface:
• 7” Touch colored LCD
• Tile based menu configuration
• Easy to use
• Know results with the changing colors
Advanced Flow Chemistry:
• Quartz glass flow cuvette: Accurate & error free results
• 18 μL flow cuvette – lower reagent aspiration: Economical
• Ease of testing: Use Flow Cuvette, Macro, Semi-micro or Micro Round tubes
Yumizen CA40
Semi-automated Clinical Chemistry Analyzer
Yumizen CA40 is a semi-automated Clinical Chemistry analyzer with facility to perform Chemistry, Immunoturbidimetry and Coagulation Tests (PT & APTT). It is an ideal solution for small laboratories with the facility to perform a wide range of biochemical tests.
Features:
• Semi-automated Clinical Chemistry analyzer with coagulation tests capacity (PT & APTT)
• 8 incubation positions for chemistry tests and 5 positions for coagulation tests
• 8-inch colored touch screen display
• Tri-level Quality Control with Levey-Jennings chart
• 6 filters with additional 2 open positions
POCT
Microsemi CRP LC-667G
Hematology Analyzer
World exclusive concept: Simultaneous blood analysis + CRP measurement, along with data management
• CBC+CRP results in 4 minutes (15 tests / hour)
• CBC results in 1 minute (55 tests / hour)
• 19 parameters
• Open Tube
Features:
• Highly compact and lightweight
• Micro-sampling on whole blood: CBC: 10μL / CBC+CRP: 18μL
• Precise cellular identification through electronic impedance variation method
• Haemoglobin measurement with photometry
• CRP measurement with immunoturbidimetry technology
CRP:
• Ready and easy to use CRP reagent
• No need to take the CRP reagent out after use
• Integrated thermal printer (full data printout, including PLT, RBC and WBC curves)
• User-friendly interface (colour touch screen, virtual keyboard)
• Data transfer with flash card (archiving to PC, upload of QC target values)
